CL-TRX16-V1D
HD TVI / CVI / AHD Video Fiber Optic Transmission
- Automatically identify formats of input videos
- Support transmission of 16 channel HD TVI / CVI / AHD video signal and controlling data
simultaneously though coaxial cable - Advanced lightning protection design, support 3kv lightning protection
- Single fiber transmission, optional 20km, 40km, 60km, 80km long-distance transmission
- Supports 1280x720P / 30Hz, 1920x1080P / 30Hz 2560x1960P / 30Hz resolution analog
high-def inition coaxial video with 3 megapixel, 4 megapixel and 5 megapixel pixel cameras,
and broadcast-quality transmission quality - Uncompressed real-time transmission to ensure the best video transmission effect
- Industrial-grade design, SMT process
- Dimension(mm) : 483W x 44H x 220D
