LK-101
Loop Detector
- Self-tuning Range : 50 to 1000μH
- Sensitivity : Four step switch selectable
- Filter : Switch selsctable 2 Second filter
- Presence Relay : Fail-safe
- Pulse Relay : Switch selectable (Pulse on detect, Pulse on undetect)
- Response Times : 10 ms
- LED Indicator : Power (Red) / Detect (Green)
- Relay Rating : 5A @ 230VAC
- Power Requirements : 230V AC ±15%
- Operating Temperature : -20°C to 65°C
- Mounting Postion : Shelf or DIN rail mounting
- Connections : 11-pin submagnal type
- Dimension(mm) : 40W x 78H x 108D
