TA-208

Power Supply Unit

  • 220 - 240VAC, 50Hz Input Voltage
  • 12VDC at 3Amp high current unregulated power source for electric door lock striking
  • 14VDC at 1A regulated power source for access control device
  • Short circuit protected with replaceable fuse
  • Controllable timing (0-15 seconds adjustable) relay output contacts for "NC" or
    "NO" door lock strike
  • Compatible with all the digital keypads
  • Dimension(mm) : 182W x 82H x 73D
