CL-801PI
PoE Injector
Gigabit PoE Injector IEEE802.3at
CL-801PI enables both home and office users to easily connect and supply power to
Network devices such as wireless Access Points (APs), IP cameras, and IP phones while
adding more Ethernet devices like computers, printers, and Network Attached Storage
(NAS) onto a network.
Built with home and small business users in mind, this compact PoE injector making it
ideal for use in virtually any room or office. The UTP CAT-5/ CAT-5e/ CAT-6 cable can
extend up 328ft (100m) deliver both Ethernet and power. This CL-801PI save the power
construction while installation.
CL-801PI is stable and powerful PoE Midspan which can feed the power through UTP
cable to the Standard IEEE802.3af/at PoE devices. It make the installation of the
network devices easily. CL-801PI fits for different environment from AC 90~260V wide
range of input. With full 30W of power, it can deliver the power up to 100m. The circuit
design also consideration the surge issue. The surge protection can up to 15KV.
- Connector : RJ-45 x2 (Data in / data + Power out)
- Ethernet Data Rate : 10/100/1000Mbps (vary on Ethernet device attached)
- Power Input : AC 90~260V, AC socket
- Power Cord : US/UK/EU/AU Plug type
- Dimension(mm) : 88W x 166H x 51D
