Product
HD-20KD
Automatic Door Sensor
- Protection Standard : IP55
- Technology : Infrared
- Receiver : ≤ 15 Meters
- Detection Time : ≤ 6 ms
- Range : Range can be reduced to 30% in bad weather
- Infre-red Frequency : 1.92 kHz
- Power Supply : 12 to 24V DC/AC
- Wave Leungth : 940nm
- Input : RX 15mA - TX 30mA
- Operating Temperature : -20°C to 70°C
- Relay Output Contact : 1A max 30V
- Dimension(mm) : 49.5W x 26.5H x 76D
