Product
ETC-BR400CBG
Standard Barrier
- Diversified booms with different length available, up to 5 meters maximum,
which offers wide scope of application. - DC permanent magnet synchronous motor(PMSM), servo control.
- Bi-direction boom holder design:
left / right installation can be exchanged easily and quickly. - Double tension spring crank transmission design, for more stable and reliable
structure. - Eliminate limit switch design, accurate encoder detection, detecting boom position
when power on. - Adjustable open/close speed control (2-5 sec)
- Built-in delay auto-closing and reverse on obstacle in case of resistance.
- Integrated RS485 communication, infrared photocell and loop detector interface.
- Traffic Light interface (AC220V, can support lamp with 40W)
- Case Dimension(mm) : 310W x 980H x 240D
